Bale trailers

Agricultural farm bale trailers

Our standard bale trailer specifications

Here's what makes our trailers solid and reliable!

Terra-Line bale trailers are available in Tandem axle (22ft, 24ft, 26ft, 28ft, 30ft or 32ft) or Tri-axle (30ft, 32ft, 36ft or 40ft).

• Distag QCS 10 stud commercial axles on a York ultra underslung triple-leaf parabolic suspension
• Bolt-on, half swivel hitch
• Channel side rails with strapping holes to allow legal strapping anywhere on the trailer
• Dynamic LED lighting kit with indicators on side markers
• Reflective chevron tape
• Adjustable rear bumper, front swan neck, and drawbar skid – all galvanized
• Slide-in lade brackets
• Stainless steel toolbox

Steel Sizes :

• Chassis = 250x150x6 box section
• Draw bar = 250x150x6 box Section (Welded/Fixed solid with Anti Twist plates welded inside)
  Headboard frame = 100 X 50 X 3.5 / 500mm Tall (welded/fixed solid) Headboard and Tailboard plates = 5mm
• Side Rails = 125mm X 65mm C section with 30mm holes every 4 ft. C/W Chamfered front edges Galvanised Rear Bumper = Adjustable mounting plates allows bumper to tuck out the way

Running Gear :

• Axles > 127 X 2045 High Speed (105kph) commercial 10 stud axles
• Brakes > 420 X 180 drums with Oil brakes / Manual hand brake connected to front axle Wheels and Tyres > 445/45 19.5 LongMarch Mini Super single assemblies
• Suspension > York Ultra Underslung assembly with 76mm X 3 Leaf springs (1000mm Bed hight) Hydraulic components > Hydroscand twin braded high UV spec’d pipe and fittings
  (Bulk head oil brake fitting on swan neck for short replacement of damaged pipe)

Optional Extras for Terra-Line Bale Trailer

• Flooring options
  • 3mm steel floor ( 964mm Bed Height )
  • 4.5mm Steel Tread Plate floor ( 965mm Bed Height )


• Sprung Draw bar ( single mono leaf behind headboard, Galvanised bolting plate )


• Brakes
  • Air & Hydraulic Brakes (Shunt valve under side rail)


• Bale lades

  • Front and rear bale ladders for 2 bales high (Galvanised)
  • Front and rear bale ladders for 3 bales high (Galvanised)
  • Cranked lades


• Lighting
  • Front Dynamic LED Indicators (Audi style)
  • Guarded Twin strobe lights


• Swivel or spoon hitch
• Second Strap Box, Black (350mm Tall)
• Stainless toolbox (400mm Tall)
• Front mud guards and flaps
• Side rail sockets with 1250mm Posts c/w storage
• Full Side Crash Bars
• Rear Towing Eye
